MICRODOS OEM PERISTALTIC HOSE PUMPS
Microdos OEM
The Microdos OEM peristaltic hose pumps are suitable for integration into systems for dosing, dispensing, vending, pumping, and bottle filling.The units are available in a range of flow rates from 60ml/min up to 17L/min and with various motor specifications depending on the application e.g. commercial vending machines, hygienic or dirty industrial and mining environments.
- Printers & packaging machines
- Chemical dosing
- Washing machines
- Various vending machines
- Air conditioning
- Water treatment plants
Microdos MP2
Peristaltic pump with fixed flow rate
Reinforced PP body
Polycarbonate front panel
Standard Power Supply 230 Vac
100 % Made in Italy
CE approved
| Type | Maks. kapacitet | Maks. afgangstryk | Maks. temperatur | Slangemateriale | Optioner | Rotor | Pumpehoved |
|---|---|---|---|---|---|---|---|
| M045 | 60 ml/min | 2 bar | 85 °C | Santoprene. Silikone. Viton® or Tygon® | 3 rollers. encoder | - | - |
| M025 | 260 ml/min | 2 bar | 85 °C | Santoprene. Silikone. Viton® or Tygon® | 3 roller. encoder | 2 ruller med hurtig rørbelastningsfunktion | - |
| Mini load | 380 ml/min | 2 bar | 85 °C | - | - | 4 ruller | - |
| M500 | 730 ml/min | 2 bar | 85 °C | Verderprene. Silikone. Viton® or Tygon® | 3 ruller. fremmedventilation (110/230 V) | - | - |
| M60 | 375 ml/min | 2 bar | 85 °C | Verderprene or Silikone | 4 ruller med Nylatron eller Delrin | - | - |
| EZ | 1260 ml/min | 2 bar | 85 °C | Verderprene. Silikone. Viton® or Tygon® | Børsteløs (24 Vdc) | Polycarbonat. 316 rustfri stål indsatser med Nylatron ruller | - |
| M1500 | 2200 ml/min | 2 bar | 85 °C | Verderprene. Silikone. Viton® or Tygon® | fremmedventilation (kun 110/230V. 50/60Hz) | - | Sort cyclooy med støtteleje |
| MP2 | 30 l/h | 3 bar | 85 °C | Santoprene or Silicon | 24 Vdc | - | - |
Any questions?
Find out more about Hose Pumps and Microdos OEM from Lobe
Our technical sales staff looks forward to your inquiry!
